6 GHz High Bandwidth Digital Signal Oscilloscope
The Keysight DSOX6004A InfiniiVision oscilloscope provides 4 channels with up to 6 GHz bandwidth and 20 GSa/s sampling, enabling accurate capture of high-speed digital and RF signals. It supports long acquisitions with up to 2 Gpts of memory, hardware-accelerated triggering, and integrated jitter, eye diagram, and protocol analysis. Measurement fidelity is enhanced by a low-noise front end, with an input-referred noise floor of ~115 µV rms at 1 GHz and ~210 µV rms at 6 GHz, and an effective number of bits (ENOB) approaching 9 under favorable conditions. A waveform update rate exceeding 1 M wfms/s allows detection of rare events, while LAN, USB, and HDMI interfaces facilitate use in automated R&D or production test environments.
Programmable Bidirectional DC Supply (18 kW)
The ITECH IT6018C-1500-40 is a bidirectional DC power supply rated for up to 18 kW, with an output range of 0–1500 V and 0–40 A. It operates in constant voltage, current, or power modes, and supports seamless transition between sourcing and sinking for realistic device testing. Regenerative capability returns absorbed energy to the grid, improving efficiency in long-duration tests. The supply offers fast dynamic response, precise regulation, and built-in protection functions (OVP, OCP, OPP, OTP) for safe operation under high-power conditions, making it suitable for applications such as EV drivetrains, renewable systems, and energy storage validation.
Programmable DC Electronic Load (12 kW)
The ITECH IT8012-500-80 is a high-performance programmable DC electronic load designed for testing power supplies, batteries, fuel cells, and other high-power devices with up to 12 kW of power dissipation capability. Operating at up to 500 V and 80 A, this model provides multiple operating modes including constant current (CC), constant voltage (CV), constant resistance (CR), and constant power (CP), ensuring versatile testing flexibility across a wide range of applications. It features high-speed dynamic response, automatic range switching, and precision measurement functions, making it suitable for both steady-state and transient performance evaluation. With built-in protection functions such as over-voltage, over-current, over-power, and over-temperature safeguards, it ensures safe and reliable operation during demanding test conditions.
Grid Simulator (21kVA)
The ITECH IT7900EP Regenerative Grid Simulator is a high-performance, programmable AC/DC power source designed for grid simulation, renewable energy testing, and compliance evaluation of power electronic devices. Offering output power up to several hundred kilowatts with parallel operation, it supports single-phase, three-phase, and multi-channel configurations, providing flexible test capabilities for applications such as PV inverters, EV chargers, smart grids, and microgrids. The IT7900EP features wide voltage and frequency ranges, precise waveform generation, and advanced programmable functions to emulate grid disturbances, harmonics, and unbalanced conditions with high accuracy. Its regenerative design allows bidirectional power flow.
